6AH-14301-00-00 Carburetor Assembly Fits Yamaha Outboard F15 (15 HP), F20 (20 HP)

Product Overview

XR MARINE · CARBURETORS & REPAIR KITS

6AH-14301-00-00 Carburetor Assembly Fits Yamaha Outboard F15 (15 HP), F20 (20 HP)

This product is a replacement carburetor assembly configured as a 20 HP carburetor application for the stated Yamaha and Parsun F15 and F20 outboard engines from 2006 onward. It is designed for full carburetor unit replacement rather than partial internal repair, and it comes supplied with two matching mounting gaskets (6AH-13646-00). Before ordering, compare your complete original carburetor reference number—including the suffix—and verify your full engine model designation rather than selecting by horsepower alone.

Product Specifications

Key product details for identification and comparison.

Fitment

The 6AH-14301-00-00 Carburetor Assembly from XR Marine fits Yamaha Outboard and Parsun F15 (15 HP) and F20 (20 HP) outboard engines from 2006 onward in the applications listed below.

Verify the complete engine model designation on your identification plate against the individual application records below, and match your complete OEM carburetor reference number including its suffix. Horsepower alone cannot confirm compatibility, and you should keep 6AH and 6AG number prefixes distinct when checking your existing unit.

• Brand: Yamaha / Parsun | Model: F15 | Power: 15 HP | Year: 2006 onward (end year not stated) | Configuration Note: 20 HP carburetor configuration
  ✓ Fits
• Brand: Yamaha / Parsun | Model: F20 | Power: 20 HP | Year: 2006 onward (end year not stated) | Configuration Note: 20 HP carburetor configuration
  ✓ Fits

OEM & Part Number References

Use the complete reference number, including its suffix, when comparing parts. Reference numbers do not confirm that every version is interchangeable.

References ending in A0, F0, F1, F2, B2, 50, or 51 should not be treated as interchangeable solely because they share the same number family. Keep 6AG references distinct from 6AH references when checking your existing carburetor. Note that gasket 6AH-13646-00, fuel pump 6AH-24410-00, and repair kit references 6AH-W0093-00-00 / 6AH-W0093-00 are separate associated component numbers, not alternative carburetor assembly numbers.

What's Included

Check the supplied components before planning your repair.

• Carburetor (OEM reference: 6AH-14301-00-00) — Included
• Gasket (OEM reference: 6AH-13646-00) — Quantity: 2

Installation Guide

General installation overview. Follow the service manual for your exact engine and carburetor configuration. Fuel-system work requires the appropriate skills and precautions.

1. Verify identification and supplied parts: Before starting disassembly, check the engine identification plate, compare the complete part number (including prefix 6AH vs. 6AG and suffix) on your existing carburetor, and confirm the supplied carburetor assembly and two 6AH-13646-00 gaskets match your application.
2. Prepare the engine safely: Shut off the engine, allow it to cool completely, disconnect the battery or disable the ignition system, and shut off or isolate the fuel supply according to your service manual. Work in a well-ventilated area away from any ignition sources.
3. Document routing and linkages: Take clear photos or notes of all fuel hoses, vent tubes, throttle linkages, and choke connections attached to the carburetor so they can be restored to their exact positions.
4. Remove the existing carburetor assembly: Drain the float bowl safely into an approved container, disconnect the fuel lines and linkage arms without bending them, and remove the mounting bolts and old carburetor unit following the sequence in your service manual.
5. Inspect flanges and compare units: Carefully clean old gasket residue from the intake manifold and air intake mating surfaces without scratching the metal. Place the old and new carburetors side by side to confirm matching flange geometry, throttle lever orientation, and hose fittings.
6. Install the new carburetor and gaskets: Position the supplied 6AH-13646-00 gaskets and mount the replacement carburetor assembly. Tighten the mounting fasteners evenly according to the specifications in your engine service manual, then reconnect the linkages and verify smooth, full-range throttle and choke movement without binding.
7. Check for fuel leaks and test operation: Reconnect the fuel line, prime the fuel system, and inspect all fittings, hoses, and gasket joints for any sign of fuel leakage. With proper cooling water supplied to the outboard, start the engine and follow your service manual for any required idle or linkage checks. Shut the engine down immediately if any fuel leak, throttle sticking, or abnormal running occurs.

Before You Order

A careful fitment check helps you choose the right part the first time.

• Match the full engine model designation on the identification plate.
• Check the individual year entry and any serial-number or version restrictions.
• Compare the complete OEM reference number, including its suffix. Horsepower or appearance alone is not enough.
• Confirm the package contents and the quantity needed for your repair.
• Do not treat references ending in A0, F0, F1, F2, B2, 50, or 51 as automatically interchangeable solely because they share the same number family, and keep 6AG references distinct from 6AH references.
• Confirm that your engine requires this 20 HP carburetor configuration for a 2006-onward Yamaha or Parsun F15 / F20 application, and note that fuel pump 6AH-24410-00 is a separate part not included in the package.

Need help checking fitment? Have your engine identification details, the existing part number and clear photos ready when you contact XR Marine.
